HQD: Spindle Motor
HQD has earned a reputation as a leader in spindle motor technology, boasting over two decades of industry experience. Renowned for their precision engineering and comprehensive product range including the GDL, GDK, GDZ, and GDF series. HQD sets the standard for reliability and performance in industrial applications.
Two-axis heads, aggregates, CNC boring heads, C axis, PM Synchronous Spindles, ATC spindles, MTC spindles. HQD a global footprint and a commitment to quality, HQD continues to deliver cutting-edge solutions that empower businesses worldwide.
Product Features
- for efficient temperature control.
- 18000 - 24,000 RPM.
- for easy installation.
- long-term operation.
- with efficient power consumption.
Technical Specification
- 0.8 kW to 7.5 kW
- Water & Air Cooling
- 220V & 380V
- ER series (model dependent)
Models
Available Series & Models
HQD Spindle GDF46-18Z/2.2 & GDZ-24-1B
- 18000 / 24000 RPM
- 2.2KW/3.2 kW
- 1.17/0.88Nm
- 220/380V
- 7.8/4.4A
- 300/400HZ
- ER20-Φ3.175-Φ13
- Air Cooling / Water Cooling
- Grease
- 2*7005C P4,1*7002C P4
- 7Kg
HQD Spindle GDF65 24Z/0.8
- 18000 / 24000 RPM
- 0.8 KW
- 0.22 Nm
- 220/380V
- 3.0/1.6 A
- 400 Hz
- ER11-Φ3.175-Φ7.0
- Air Cooling / Water Cooling
- Grease
- 27002C P4, 27000C P4
- 3.0 Kg
HQD Spindle GDF53-18Z/ 3.5
- 18000 / 24000 RPM
- 3.5KW
- 1.59/1.36Nm
- 220/380V
- 12/7A
- 300/400HZ
- ER25-Φ3.175-Φ16
- Air Cooling / Water Cooling
- Grease
- 2*7007C P4,2*7002C P4
- 8Kg
HQD Spindle 'GDF60-18Z/4.5
- 18000 / 24000 RPM
- 4.5KW
- 2.39/1.79Nm
- 220/380V
- 15/9.0A
- 300/400HZ
- ER25-43.175-016
- Air Cooling / Water Cooling
- Grease
- 2+7007C P4.2*70020 P4
- 12Kg
HQD Spindle GDK125-18-24Z/5.5
- 18000 / 24000 RPM
- 5.5KW
- 2.92Nm
- 220-380V
- 19/11 A
- 300-400 HZ
- ER25-Φ3.175-416
- Air Cooling / Water Cooling
- Grease
- 2X7007C 2X7205C
- 23Kg
HQD Spindle GDF60-18Z/6.0
- 18000 / 24000 RPM
- 6.0KW
- 3.18Nm
- 220/380V
- 21/12.0A
- 300HZ
- ER32-Φ3.175-Φ20
- Air Cooling / Water Cooling
- Grease
- 2*7008C P4,2*7002C P4
- 13Kg
HQD Spindle GDK125-24Z/7.5
- 18000 / 24000 RPM
- 7.5KW
- 3.98Nm
- 380V
- 15.0A
- 300HZ
- ER32-Φ3.175-Φ20
- Air Cooling / Water Cooling
- Grease
- 2*7008C P4,2*7004C P4
- 16Kg
More Information
HQD: Spindle Motor Application
Air Cooled Spindle:
• Wood Cutting
• Wood Engraving
• 3D Carving
• Drilling
• PCB Cutting
Water Cooled Spindle:
• Marble Cutting
• Marble Engraving
• Stone Cutting
• 3D Structure
• Drilling
• Metal Engraving
